Galvanized screw piles consist of a high-strength pile shaft, continuous helical blades, and a connecting head. This product can be quickly installed using mechanical screwing methods, and utilizes the interlocking action between the blades and the soil to provide stable tensile load-bearing capacity. It is suitable for ground anchoring and foundation support applications requiring rapid construction.
Product Parameters
|
Structural dimensions |
Pile shaft diameter: 76/89/114 mm; Blade diameter: 150-400 mm; Length: 1-3 m (customizable) |
|
Materials and Corrosion Protection |
Material: Q235B/Q355B steel; Surface treatment: Hot-dip galvanizing (zinc coating ≥ 85μm) |
|
Installation and Load Bearing |
Final installation torque: 1500-4500 N·m; Single pile uplift capacity: 10-100+ kN (requires on-site testing for confirmation) |
|
Implementation standards |
Material standard: GB/T 700; Corrosion protection standard: ISO 1461; Design reference: IBC/ACI and other international standards. |
Product Features
Overall Hot-Dip Galvanized Corrosion Protection
Using the hot-dip galvanizing process, the zinc layer thickness is typically ≥60–85μm, providing salt spray corrosion resistance for 500–1000 hours, and a service life of over 20 years in ordinary soil environments.
Stable Stress Distribution on Spiral Blades
The spiral blades typically have a thickness of 4–10mm and a diameter of 200–350mm. They are fully welded or integrally formed with the pile shaft, resulting in low drilling resistance. After installation, the single pile's pull-out resistance can reach 30–150kN.
High Construction Efficiency
The screw-in installation method eliminates the need for excavation and concrete pouring. Installation of a single screw pile is typically completed within 5–15 minutes and can be performed in environments ranging from -10℃ to 45℃.
Strong Specification Adaptability
Common pile diameters are Φ76–Φ219mm, with lengths of 1–3m. Lengths can be extended to over 5m using extension sections. The load-bearing capacity can be flexibly adjusted according to the pile type and soil conditions.
Applications
New Energy Infrastructure
Foundations for Ground-Mounted Photovoltaic Power Plants
01
Temporary Facilities
Construction Fences, Temporary Stages, Event Grandstands, Pipe Supports
02
Municipal and Landscape Engineering
Road Guardrails, Streetlights, Monitoring Pole Installation
03
Agricultural and Ecological Facilities
Greenhouses, Livestock Fences, Soil and Water Conservation Engineering Foundations
04
Emergency and Special Uses
Temporary Anchoring for Disaster Relief and Field Operations
05
One-Stop Service
Provides English technical documents and completes preliminary load calculations and selection recommendations within 48 hours.
Utilizing a professional system, we provide full-process tracking from order placement to shipment, with daily production progress updates.
Uses anti-rust packaging + customized reinforced wooden pallets to ensure a product integrity rate of over 98% during sea transport.
Assists in preparing a complete set of export documents (packing list, invoice, certificate of origin, etc.), and can provide door-to-door logistics solutions through our partner freight forwarders.
FAQ
Q: What is the relationship between installation torque and bearing capacity?
A: The final installation torque is positively correlated with the pull-out bearing capacity and is a key on-site control indicator. However, the precise bearing capacity must be ultimately verified through on-site pull-out testing.
Q: Can Galvanized Screw Piles be reused?
A: Yes. They can be unscrewed and reused without damaging the pile body and helical blades.
Q: Can the galvanizing layer thickness be customized?
A: The galvanizing layer thickness can be adjusted according to customer requirements or the operating environment.
